Filter screen tee Basic Parameters
型号 | 材质 | 颜色 | 长 Length | 高 Height | 对角中心孔距 Diagonal center distance （mm） | 通道内径 Inner bore diameter（mm） | 平行中心孔距Center distance of parallel holes（mm） | 适用车型 |
| DN50 | Aluminum Alloy | Metallic | 115 | 115 | 125 | 71 | 90 | Water sprinkling & Sewage suction |
| DN80 | Aluminum Alloy | Metallic | 134 | 134 | 150 | 85 | 107 | Water sprinkling & Sewage suction |
Filter screen tee DN50 | With 71mm inner bore and compact structure, DN50 valve occupies little mounting space, perfectly matching 5-8ton mini sprinkler & sewage suction trucks as well as branch auxiliary pipelines. Its compact hole spacing minimizes chassis hole reworking to save retrofit expense. This small bore realizes precise flow regulation: fine mist watering on sprinkling end and targeted sludge suction at vehicle corners, ideal for narrow urban road sanitation. Superior lightweight property lessens vehicle load and fuel consumption for short-distance daily operation. |
| Filter screen tee DN80 | Featuring 85mm large inner bore, DN80 allows high fluid throughput to avoid sludge clogging, greatly boosting sprinkling and sewage suction efficiency for over 10ton heavy-duty sanitation vehicles. Larger diagonal & parallel center hole spacing delivers stronger fixing strength against high working pressure to prevent loose installation. Designed for heavy-load farm, construction and suburban septic tank cleaning, it stands as core fitting for high-frequency intensive waste disposal in harsh working conditions. |
2
Real Shot Display of Filter screen tee
Filter screen tee
Filter screen tee
Filter screen tee
1
Filter screen tee
Filter screen tee DN80 features a larger inner bore diameter, delivering significantly higher water & sewage flow capacity than DN50. Select DN80 for high-flow pipeline systems and DN50 for medium & low-flow applications.
2
Filter screen tee
Filter screen tee DN80 has larger mounting hole spacing and overall dimensions, with bigger matching flange and base sizes; the two models cannot be directly interchanged for installation.
3
Filter screen tee
Filter screen tee DN50 fits pipelines with DN50 nominal diameter, for medium & small-sized water sprinkler and sewage suction trucks; DN80 matches DN80 pipes, designed for main pipelines of large sanitation vehicles.
3
Filter screen tee Application Advantages
Filter screen tee Application Advantages
◆Integrated tee & filter design combines flow diversion and impurity filtration in one piece, reducing extra pipe fittings and leakage risk.
◆Built-in screen blocks gravel, fabric and debris to protect vacuum pump and water pump from abrasion, prolonging pump service life.
◆Detachable filter screen for easy cleaning without pipeline disassembly, convenient daily maintenance.
◆Aluminum alloy housing features anti-corrosion & anti-impact performance, suitable for harsh sewage & water intake working conditions of sanitation trucks.
◆Two sizes DN50 & DN80 available to fit small/medium and large sprinkler & sewage suction trucks respectively.
Filter screen tee Installation Position
◆For sewage suction truck: Main suction pipe in front of liquid ring vacuum pump;
◆For sprinkler truck: Water intake pipeline before water pump, near water tank connection.
Core rule: Install on pump inlet side to filter impurities before medium flows into pump.
